• Large Dual Display
  • Three to Eight Separate
    Temperature Zones
  • Self-Tune
  • Fuzzy Logic
  • 100 Ohm RTD Input
  • Loop Break Protection
  • Peak/Valley Indication
  • Illuminated Keypad
  • Master On/Off Switch
  • Four Password
    Protected Security Levels
  • RS-485 Serial Communications
  • Output: 10A SSR per Zone
  • Supply Voltage: 208V/3Ø/30A Circuit
  • Accuracy: ±0.25% of span,
    1 least significant digit
  • Memory Backup: Nonvolatile memory
  • Front Panel Rating: NEMA 4X (IP66)
  • Agency Approvals: CE, UL.

For applications requiring multiple temperature zones, the 116-MZ temperature controller is the answer. Configurable for 3-8 separate temperature control zones in a single rack mounted housing, it uses the same quality 1/16DIN units as our Single zone controllers. Load power is fuse protected and can be switched on and off from the front panel. Power input to the control is via One (208V/3Ø/30A) circuit with a NEMA L-2130 twist lock receptacle. Load power is supplied through a Deutch 7 pin circular connector

The Series 116-MZ comes with 3-8 single set-point and dedicated limit alarm, Fuzzy Logic, Auto-Tune, Peak/Valley indication, Percent Output indication and Heater Break protection. Process protection features include open sensor protection, shorted sensor protection, input rate of change protection and loop break protection.
