Material: Calendared Reinforced Silicone rubber
-
-
Temperature Range: -45° to 220°C (-49° to 428°F)
-
Maximum temperature for UL® Recognition: 220°C (428°F)
-
Maximum Exposure Temperature: 260°C (500°F)
-
Wattage Range: 2.0 Watt/ in2
-
Voltage Range: Up to 600V (250V max. for UL component recognition)
-
Size Range: 1” wide, 2” wide; 2’ to 16’ lengths.
-
Thickness: 0.032″ to 0.080″ ± 0.003″
-
Leads: Teflon with silicone over braid
-
Standard Connection: AMP CPC Circular connectors 4-position; Size 11.
-
-
ETL #4003145 ANSI/UL STD 499
-
Chemical and moisture-resistant
-
UL 220/220 Rated Materials
-
-
-
Thermal insulation vulcanized to the heater
-
-
Available Accessories: Controls and Sensors (100 Ω RTD, 1000 Ω RTD, and thermocouples J, K, and E)
